The Kit includes:

Main body

Vac-formed interior tray

Driver (body and head separately)

Vac-formed windows

Exhaust pipes

Painting+masking tray (attaches to PGR painting stand)

Chassis options: (include bushings and front axle height adjustment screws)

(1) one-piece inline chassis for FC-130 (shortcan)

(2) chassis and inline pod for FF-050 (slimline). (Under development) Includes spring-damped pod with hard/medium/soft options for damping adjustment. This version is being developed to race against the MR Slotcar Corvette.

Front wheel inserts

Rear wheel inserts



The kit does not include:

Guide, braid, motor, gears, wheels, tyres, decals



Here is a list of the parts around which I designed this model:

Guide:   NSR 4859 pick up guide – racing w/large keel, suitable for wooden track

Braid:    Your choice. My personal choice is Sloting+ SP104137 copper braid (0.25mm thickness) - 2 metre with dispenser

Motor:   Again, your choice. FC-130 (short can) or an FF-050(slimline) motor. Refer to chassis options above. Our group races a        “classic sports car” class which specifies a 12.5K predator motor and non-pod chassis. This is the class for which I originally made this car.

Gears:   Short can 5.5mm inline pinion + 1.5mm ofset crown

              Slimline 5.5mm inline pinion (1.5mm bore) offset crown

Front wheels:   SLOTING PLUS 021104 Duraluminium wheels 3/32 (14.2 x 8.0mm)

Rear wheels:   There is space to comfortably fit up to 13mm wide tyres, but I used SLOTING PLUS 021124 Duraluminium wheels 3/32 (15.9 x 10mm)

Tyres:      Front   You could use MJK 4406 logrip front tyres - MJK vintage wide. You could also use NSR5201EVO Slick Front - No friction - 17 x 8

Tyres:      Rear:   There are many options available which will fit, so it’s up to your preference. I used NSR5254 Classic ultragrip rear tyres 20.5 x 10mm

Decals:    I don’t have a specific decal set for this car. For mine, I just used leftovers I had to make a fantasy livery.
